Hotsy 797SS - Page 20

Manual Hotsy, 700 Series • 9.808-301.0
OPERATOR’S MANUAL
PRESSURE WASHER
20
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.600-581.0 Nut, 1/4-20 Hex Nylock Ss 2
2 8.759-661.0 Label Hotsy Black Logo 10"
X 6.389" 2
3 9.802-064.0 Grommet, Rubber,
Nozzle Holder 3
4 9.803-277.0 Screw, 5/16" X 1/2",
Whiz Loc Flange 6
5 9.802-700.0 Bolt, 1/4-20 X 3/4",
NC HH (612937) 2
6 8.718-980.0 Washer, 5/16" Flat,
Sae (780452) 4
7 8.719-913.0 Top Hat, Weld Assy, 16'
Hotsy Coils 1
8 8.751-374.0 Spacer 5/8 X 1,25 Black 8
9 8.753-363.0 Locknut, 1" Npt, Black,
Nylon 1
8.753-364.0 Strain Relief Lt 1 Npt Black 1
10 9.802-782.0 Collar, 5/8" Bore Shaft 3010 4
11 8.758-460.0 Wheel 12 In. Rim Steel 4
12 8.759-047.0 Motor 5HP 1PH 200V
(797SS-208) 1
8.759-048.0 Motor 5HP 1PH 230V
(797SS) 1
8.759-053.0 Motor 6.2HP 1PH 200V
(897SS-208) 1
8.759-054.0 Motor 6.2HP 1PH 230V
(897SS) 1
13 8.759-549.0 Label Racing Hotsy
Right Side 1
14 8.759-550.0 Label Racing Hotsy Left Side 1
15 8.911-804.0 Assy, Outer Wrap 1
16 8.919-134.0 Assy, Coil, Hotsy 790 Mty 1
17 8.925-827.0 Handle Assembly 1
18 8.930-020.0 Belt Guard 700 Series Red 1
19 8.930-025.0 Belt cover Hotsy 700 series 1
20 8.930-026.0 Plate Pump Cover 1
21 8.930-044.0 Hose 3/8"X29" 2w
Sw3/8 X Jic 1
22 8.725-549.0 Bolt, 3/8" X 7-1/2" HH 2
23 9.802-814.0 Washer, 3/8" Split
Ring Lock, Zinc 3
24 8.715-582.0 Pulley, 2BK 47H (All models) 1
25 9.802-384.0 Pulley, 2BK 40H (797SS) 1
9.802-382.0 Pulley, 2BK 34H (897SS) 1
26 9.802-400.0 Bushing, H X 1-1/8 1
27 9.802-402.0 Bushing, H X 24mm 2
28 9.105-607.0 Belt, BX27 (All models) 2
29 9.802-710.0 Screw 5/16" X 1" Nc 3
30 9.802-712.0 Bolt, 5/16-18 X 1-3/4",
Nc Carriage Zinc 4
ITEM PART NO. DESCRIPTION QTY
31 9.802-819.0 Washer, 7/16" X 2 1/2",
Zinc, Pg Foot 3
32 8.719-047.0 Washer, Nylon, .390
ID X 1 OD X .25 THK 2
33 9.802-754.0 Screw, 1/4" X 1/2" Nc,
Whiz Loc Flange 7
34 9.802-104.0 Bushing, 1.00" SNAP,
P/N 2140 1
35 9.802-776.0 Nut, 5/16-18, Esna 7
36 9.802-778.0 Nut, 5/16" Whiz Loc Flange 6
38 9.802-802.0 Washer, 1/4" Flat Sae Zinc 3
39 9.198-004.0 3/8 USS F/W Zinc 3
40 9.198-014.0 Washer 21/64 X 1" 3
41 9.802-733.0 Bolt, 3/8" X 3-1/2", Tap,
Grade 2" 1
42 9.802-825.0 ▲ Clip, Retaining U-Type 4
43 9.802-900.0 Insulating Tank Bottom
Vhw,1' Blanket 1
44 9.802-904.0 Insulation Top Head
16odx8 Id Fiberglass 1
45 9.803-108.0 Ring, Insul. Retainer,
13" Dia 1
46 8.717-438.0 Insulation, Blanket,22.5
X 52,Fiberglass 1
47 8.750-647.0 Grommet, Rubber,
1 1/2" 1
48 8.930-050.0 Bumper 700 series
wrinkle black 1
49 9.802-518.0 Strain Relief, Lt, Str,
3/4 Npt .49-.71d 1
50 8.930-032.0 Brake assembly right side 1
▲ Not shown
