97-6574 • HOTSY 900-1400 GAS FIRED • REV. 10/05
OPERATOR’S MANUAL
PRESSURE WASHER
38
TRIGGER GUN ASSEMBLY PARTS LIST
ITEM PART NO. DESCRIPTION QTY.
14 ✪ Plunger Seat 1
15 914141 Trigger Pin 1
16 860495 Left Gun Shell 1
17 735316 Phillips Screw 6
18 914142 Trigger Lock Pin 1
19 960271 Trigger 1
20 881941 Trigger Lock Lever 1
21 936460 Inlet Pipe Seat 2
22 914285 Inlet Pipe 1
23 851190 Inlet Fitting 1
24 860496 Right Gun Shell 1
Replacement Parts
✪ 877471 Trigger Gun Repair Kit
To Next Page
