TEST MENU
30 SERVICE MANUAL
REVISION 04/19, SW: 3.51
Value Function Description
d16 Core probe
temperature
This function is not available on B models.
C and K models can use only one core temperature
probe.
Here it is possible to read the current temperature of
the core temperature sensor, P2 + P2A.
In the field next to ”Temperature”, the current tempe-
rature is shown. If ERR appears, the
sensor circuit is defective.
In the field next to ”Time”, an adjustment value
between 80 and 120 (default 100) is shown.
To adjust the temperature, press the time key until the
digit in the display flashes. Then adjust
upwards or downwards until the correct temperature
is shown. Finally, press the time key
again to save the setting.
The temperature can be adjusted by +/- 10°C.
You change between the various measuring points of
the core temperature probe by pressing
the step key.
1 = Core temp.probe 1, point 1, 2 = Core temp.probe,
point 2, 3 = Core temp.probe 1, point 3.
4 = Core temp.probe 2, point 1, 5 = Core temp.probe,
point 2, 6 = Core temp.probe 2, point 3.
d17 Steam
generator
temperature
Here it is possible to read the current steam generator
temperature, P3.
In the field next to ”Temperature”, the current temper-
ature is shown. If ERR appears, the
sensor circuit is defective.
In the field next to ”Time”, an adjustment value
between 80 and 120 (default 100) is shown.
To adjust the temperature, press the time key until the
digit in the display flashes. Then adjust
upwards or downwards until the correct temperature
is shown. Finally, press the time key
again to save the setting.
The temperature can be adjusted by +/- 10°C.
