GAS PRESSURE
64 SERVICE MANUAL
REVISION 04/19, SW: 3.51
GAS PRESSURE
1. Prepare the gas-pressure meter.
2. Open the gas-test nipple using a flat-headed screwdriver.
3. Turn the screw counter-clockwise.
When the gas-test nipple is opened, gas will escape. Be prepared and
have the gas-pressure meter ready before opening the test nipple.
Note: Local regulations might state otherwise. Please comply with local rules and
regulations.
1. Close the gas-test nipple using a flat-headed screwdriver.
2. Turn the screw clockwise.
Check all gas lines for gas leakages using an appropriate leakage
tester.
Measure the static gas pressure.
1. Switch on the unit and measure the dynamic gas pressure. The dynamic gas
pressure must be between the following values
• “1.8-2.5 kPa” - “18-25 mbar” for natural gas.
• “3-5.7 kPa” – “30-57 mbar” for LPG.
