GAS BURNER SETTINGS
SERVICE MANUAL 65
REVISION 04/19, SW: 3.51
GAS BURNER SETTINGS
Adjustment “CE” gas ovens (burner 1)
Houno Gas Oven Adjustment Settings Hot Air Burner 1 “Bottom”
O
2
%, CO
2
%
“MAX” RPM
O
2
%, CO
2
%
“MIN”, RPM
RPM Adjustment
normal operation
Air Proving
Switch - ON
Type of gas
Heat
power
kW
Ovn
types
Gas inlet
pressure
O
2
% CO
2
% RPM kW O
2
% CO
2
% RPM
“u16”
Min
“u16”
Start
“u16”
Max
OFF -> ON
Nature gas
(G20)
13 kW 1.06/5 18-25 mbar 4.1% 9.4% 6700 13 kW 4.6% 9.1% 4800 4800 4800 6700 3100 +/-100
21 kW 1.10/8 18-25 mbar 4.3% 9.3% 6300 21 kW 4.1% 9.4% 2700 2700 3900 6300 2300 +/-100
42 kW 1.20/15 18-25 mbar 4.3% 9.3% 6300 21 kW 4.1% 9.4% 2700 2700 3900 6300 2300 +/-100
21 kW 2.06 18-25 mbar 4.1% 9.4% 6200 21 kW 4.1% 9.4% 3800 3800 3900 6200 2800 +/-100
24 kW 2.10 18-25 mbar 4.1% 9.4% 6600 24 kW 4.5% 9.2% 2800 2800 3600 6600 2300 +/-100
48 kW 2.20 18-25 mbar 4.1% 9.4% 6600 24 kW 4.5% 9.2% 2800 2800 3600 6600 2300 +/-100
Nature gas
(G25)
13 kW 1.06/5 18-25 mbar 4.0% 9.3% 6800 13 kW 4.3% 9.1% 4800 4800 4800 6800 3100 +/-100
21 kW 1.10/8 18-25 mbar 4.0% 9.3% 6400 21 kW 4.0% 9.3% 2800 2800 3900 6400 2300 +/-100
42 kW 1.20/15 18-25 mbar 4.0% 9.3% 6400 21 kW 4.0% 9.3% 2800 2800 3900 6400 2300 +/-100
21 kW 2.06 18-25 mbar 3.8% 9.4% 6200 21 kW 3.8% 9.4% 3800 3800 3900 6200 2800 +/-100
24 kW 2.10 18-25 mbar 3.8% 9.4% 6600 24 kW 4.1% 9.2% 2800 2800 3600 6600 2300 +/-100
48 kW 2.20 18-25 mbar 3.8% 9.4% 6600 24 kW 4.1% 9.2% 2800 2800 3600 6600 2300 +/-100
LPG 3BP
(G30/G31)
13 kW 1.06/5 28-57 mbar 4.5% 11.0% 6500 13 kW 5.1% 10.6% 4800 4800 4800 6500 3100 +/-100
21 kW 1.10/8 28-57 mbar 4.5% 11.0% 6000 21 kW 4.5% 11.0% 2600 2600 4300 6000 2300 +/-100
42 kW 1.20/15 28-57 mbar 4.5% 11.0% 6000 21 kW 4.5% 11.0% 2600 2600 4300 6000 2300 +/-100
21 kW 2.06 28-57 mbar 4.5% 11.0% 6200 21 kW 4.5% 11.0% 3800 3800 3900 6200 2800 +/-100
24 kW 2.10 28-57 mbar 4.0% 11.4% 6200 24 kW 4.7% 10.9% 2800 2800 3600 6200 2300 +/-100
48 kW 2.20 28-57 mbar 4.0% 11.4% 6200 24 kW 4.7% 10.9% 2800 2800 3600 6200 2300 +/-100
LPG 3P
(G31)
13 kW 1.06/5 30-50 mbar 5.2% 10.3% 6800 13 kW 5.2% 10.3% 4800 4800 4800 6800 3100 +/-100
21 kW 1.10/8 30-50 mbar 5.4% 10.2% 6300 21 kW 5.4% 10.2% 3900 3000 3900 6300 2300 +/-100
42 kW 1.20/15 30-50 mbar 5.4% 10.2% 6300 21 kW 5.4% 10.2% 3900 3000 3900 6300 2300 +/-100
21 kW 2.06 30-50 mbar 5.4% 10.2% 6400 21 kW 5.4% 10.2% 3800 3800 3900 6400 2800 +/-100
24 kW 2.10 30-50 mbar 5.1% 10.4% 6600 24 kW 5.8% 9.9% 2900 2900 3600 6600 2300 +/-100
48 kW 2.20 30-50 mbar 5.1% 10.4% 6600 24 kW 5.8% 9.9% 2900 2900 3600 6600 2300 +/-100
When you adjust the gas burner, the tolerances are as follows:
Maximum rpm setting: +/-0.2%.
Minimum rpm setting: +/-0.2%.
