D82008753M 10/13 Chapter 9 57
If a fault occurs, you can find out what has happened by counting
the number of bars on the battery gauge that are flashing.
VSI Controller
1 bar: Low battery or a bad connection.
Try recharging the battery.
2 bars: Bad connection to left motor.
3 bars: Short circuit, left motor to battery.
4 bars: Bad connection to right motor.
5 bars: Short circuit, right motor to battery.
6 bars: Check if battery charger is still connected
to controller or controller fault.
7 bars: Joystick fault.
8 bars: Controller fault.
9 bars: Problem with brake circuit. Check that manual brake
release levers are in the drive position and power seat
lift is lowered (if equipped).
10 bars: An excessive voltage to the control system. This is
usually caused by a poor battery connection.
10 bars Rapid Flash: Powered up when joystick deflected.
Restart with joystick in neutral.
10 bars, Three Second Blink: Control is in sleep mode.
Press OFF/ON twice to restart.
Speed Bars Cycling: Controller locked.
Speed Bars Flashing: Power seat lift is inhibiting drive.
Lower the seat.
