© 2023 Hoymiles Power Electronics Inc. All rights reserved.
9
Single-phase Microinverter HMS-1600D/1800D/2000D-4T About Product / Installation Preparation
3.7 Dimensions (mm)
3.6 Terminals Introduction
Object Description
A DC Connectors
B Sub-1G Wireless Terminal
C AC Sub Connector
C
B
A
235
185
310
550
185
