i. Top cover (see Top cover on page 80)
j. Speaker assembly (see
Speaker assembly on page 82)
k. Modem module (see
Modem module on page 84)
l. System board (see
System board and system board frame on page 85)
Remove the USB/audio board:
1. Remove the two Phillips PM2.5×4.0 screws (1) that secure the USB/audio board to the base
enclosure.
2. Lift the left side of the USB/audio board (2) until the USB and audio connectors disengage from
the openings in the base enclosure.
3. Remove the USB/audio board and cables from the base enclosure.
Reverse this procedure to install the USB/audio board.
92 Chapter 4 Removal and replacement procedures

HP Compaq 8510p - Compaq Business Notebook Specifications

General

RAM	Up to 4 GB DDR2
Processor	Intel Core 2 Duo
Display	15.4-inch
Storage	80GB, 120GB, 160GB HDD
Graphics	ATI Mobility Radeon HD 2600
Operating System	Windows Vista
Weight	2.8 kg (6.2 lbs)
Battery	6-cell Li-Ion
Chipset	Intel PM965
Optical Drive	DVD+/-RW SuperMulti
Networking	Gigabit Ethernet
Audio	Integrated stereo speakers
Ports	3 USB 2.0, VGA, headphone, microphone
Slots	ExpressCard/54
