HP Compaq 8510p - Compaq Business Notebook User Manual

Torx T8M2.5×9.0 screw
Color Quantity Length Thread Head diameter
Black 19 9.0 mm 2.5 mm 5.0 mm
Where used:
(1) One screw that secures the optical drive to the computer
(2) One screw that secures the TouchPad to the computer
(3) One screw that secures the switch cover to the computer
116 Chapter 7 Screw listing

HP Compaq 8510p - Compaq Business Notebook Specifications

General

RAM	Up to 4 GB DDR2
Processor	Intel Core 2 Duo
Display	15.4-inch
Storage	80GB, 120GB, 160GB HDD
Graphics	ATI Mobility Radeon HD 2600
Operating System	Windows Vista
Weight	2.8 kg (6.2 lbs)
Battery	6-cell Li-Ion
Chipset	Intel PM965
Optical Drive	DVD+/-RW SuperMulti
Networking	Gigabit Ethernet
Audio	Integrated stereo speakers
Ports	3 USB 2.0, VGA, headphone, microphone
Slots	ExpressCard/54
