HP Compaq 8510p - Compaq Business Notebook User Manual

Left-side components
Item Component Function
(1) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
(2 RJ-45 (network) jack Connects a network cable.
NOTE: The RJ-45 (network) jack provides Gigabit
Ethernet functionality.
(3) 1394 port (select models only) Connects an optional IEEE 1394 or 1394a device, such as
a camcorder.
(4) Vent Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
(5) HDMI port Connects an optional video or audio device, such as a high-
definition television, or any compatible digital or audio
component.
(6) USB ports (2) Connect optional USB devices.
(7) Media Card Reader Supports the following optional digital card formats:
MultiMedia Card (MMC) and Secure Digital (SD) Memory
Card.
(8) PC Card slot (select models only) Supports optional Type I or Type II 32-bit (CardBus) or 16-
bit PC Cards.
Left-side components 13

HP Compaq 8510p - Compaq Business Notebook Specifications

General

RAM	Up to 4 GB DDR2
Processor	Intel Core 2 Duo
Display	15.4-inch
Storage	80GB, 120GB, 160GB HDD
Graphics	ATI Mobility Radeon HD 2600
Operating System	Windows Vista
Weight	2.8 kg (6.2 lbs)
Battery	6-cell Li-Ion
Chipset	Intel PM965
Optical Drive	DVD+/-RW SuperMulti
Networking	Gigabit Ethernet
Audio	Integrated stereo speakers
Ports	3 USB 2.0, VGA, headphone, microphone
Slots	ExpressCard/54
