HP Compaq 8510p - Compaq Business Notebook User Manual

Phillips PM2.0×5.0 captive screw
Color Quantity Length Thread Head diameter
Black 3 5.0 mm 2.0 mm 4.5 mm
Where used:
(1) Two screws that secure the hard drive cover to the computer (screws are captured on the cover by
C-clips)
(2) One screw that secures the memory module compartment cover to the computer (screw is captured
on the cover by a C-clip)
Phillips PM2.0×5.0 captive screw 113

HP Compaq 8510p - Compaq Business Notebook Specifications

General

RAM	Up to 4 GB DDR2
Processor	Intel Core 2 Duo
Display	15.4-inch
Storage	80GB, 120GB, 160GB HDD
Graphics	ATI Mobility Radeon HD 2600
Operating System	Windows Vista
Weight	2.8 kg (6.2 lbs)
Battery	6-cell Li-Ion
Chipset	Intel PM965
Optical Drive	DVD+/-RW SuperMulti
Networking	Gigabit Ethernet
Audio	Integrated stereo speakers
Ports	3 USB 2.0, VGA, headphone, microphone
Slots	ExpressCard/54
