HP Compaq 8510p - Compaq Business Notebook User Manual

9. Remove the top cover (3).
10. If it is necessary to replace the microphone, turn the top cover upside down with the front toward
you.
11. Remove the microphone cable from the clips (1) built into the top cover.
12. Remove the microphone receiver (2) from the clip (3) built into the top cover.
Reverse this procedure to install the top cover.
Speaker assembly
Description Spare part number
Speaker assembly 452225-001
82 Chapter 4 Removal and replacement procedures

HP Compaq 8510p - Compaq Business Notebook Specifications

General

RAM	Up to 4 GB DDR2
Processor	Intel Core 2 Duo
Display	15.4-inch
Storage	80GB, 120GB, 160GB HDD
Graphics	ATI Mobility Radeon HD 2600
Operating System	Windows Vista
Weight	2.8 kg (6.2 lbs)
Battery	6-cell Li-Ion
Chipset	Intel PM965
Optical Drive	DVD+/-RW SuperMulti
Networking	Gigabit Ethernet
Audio	Integrated stereo speakers
Ports	3 USB 2.0, VGA, headphone, microphone
Slots	ExpressCard/54
