4. Remove the battery (see Battery on page 45).
5. Remove the following components:
a. Keyboard (see
Keyboard on page 57)
b. Fan (see
Fan on page 61)
c. Heat sink (see
Heat sink on page 62)
Remove the graphics card:
1. Remove the two Phillips PM2.0×3.0 screws (1) that secure the graphics card to the computer. (The
edge of the board opposite the graphics card slot rises away from the computer.)
2. Remove the graphics card (2) by sliding it away from the graphics card slot at an angle.
NOTE: The graphics card is designed with a notch (3) to prevent incorrect installation.
Reverse this procedure to install the graphics card.
66 Chapter 4 Removal and replacement procedures

HP Compaq 8510p - Compaq Business Notebook Specifications

General

RAM	Up to 4 GB DDR2
Processor	Intel Core 2 Duo
Display	15.4-inch
Storage	80GB, 120GB, 160GB HDD
Graphics	ATI Mobility Radeon HD 2600
Operating System	Windows Vista
Weight	2.8 kg (6.2 lbs)
Battery	6-cell Li-Ion
Chipset	Intel PM965
Optical Drive	DVD+/-RW SuperMulti
Networking	Gigabit Ethernet
Audio	Integrated stereo speakers
Ports	3 USB 2.0, VGA, headphone, microphone
Slots	ExpressCard/54
