d. Fan (see Fan on page 61)
e. Heat sink (see
Heat sink on page 62)
f. Switch cover (see
Switch cover on page 71)
g. TouchPad (see
TouchPad on page 67)
h. Display assembly (see
Display assembly on page 75)
i. Top cover (see
Top cover on page 80)
j. Speaker assembly (see
Speaker assembly on page 82)
k. Modem module (see
Modem module on page 84)
l. System board (see
System board and system board frame on page 85)
Remove the PC Card assembly:
1. Turn the system board upside down, with the front toward you.
2. Remove the two Phillips PM2.0×3.0 screws that secure the PC Card assembly to the system board.
3. Detach the slots on the PC Card assembly from the tabs on the PC Card connector (1).
90 Chapter 4 Removal and replacement procedures

HP Compaq 8510p - Compaq Business Notebook Specifications

General

RAM	Up to 4 GB DDR2
Processor	Intel Core 2 Duo
Display	15.4-inch
Storage	80GB, 120GB, 160GB HDD
Graphics	ATI Mobility Radeon HD 2600
Operating System	Windows Vista
Weight	2.8 kg (6.2 lbs)
Battery	6-cell Li-Ion
Chipset	Intel PM965
Optical Drive	DVD+/-RW SuperMulti
Networking	Gigabit Ethernet
Audio	Integrated stereo speakers
Ports	3 USB 2.0, VGA, headphone, microphone
Slots	ExpressCard/54
