Removal and Replacement Procedures
Maintenance and Service Guide 5–3
Section Description
# of Screws Removed
5.10 Keyboard 3
5.11 Switch Cover 3 to remove the switch cover
2 to remove the power button
board
5.12 Display Assembly
Display bezel
Display inverter
Display hinges
Display lid switch module
Display panel
Wireless antenna transceivers
Microphones
6
8
4
4
1
0
2
0
5.13 Top Cove r 16
5.14 TouchPad 7
5.15 Wireless Switch Board 2
5.16 Modem Module 2
5.17 Audio/Infrared Board 1
5.18 Bluetooth Module 0
5.19 USB Board 1
5.20 Speaker Assembly 4
5.21 System Board 2
5.22 ExpressCard Assembly 4
5.23 Fan/Heat Sink Assembly 5 loosened
5.24 Processor 1 loosened
Disassembly Sequence Chart
(Continued)
To Next Page
