HP Compaq V3000 User Manual

Removal and Replacement Procedures
Maintenance and Service Guide 5–19
5.9 Optical Drive
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the Phillips PM2.5×7.0 screw 1 that secures the
optical drive to the computer.
3. Insert a thin tool, such as a paper clip, into the media tray
release hole 2. (The optical drive media tray releases from
the optical drive.)
4. Use the media tray frame to slide the optical drive 3 to
the left.
5. Remove the optical drive.
Removing the Optical Drive
Optical Drive Spare Part Number Information
DVD/CD-RW Combo Drive
DVD±RW/R and CD-RW Double-Layer Combo Drive
DVD±RW/R and CD-RW Double-Layer Combo Drive with
LightScribe
417063-001
417064-001
417065-001

HP Compaq V3000 Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Display	14.1-inch WXGA (1280 x 800) TFT LCD
Hard Drive	120 GB SATA (5400 rpm)
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g
Operating System	Windows XP Professional
Weight	2.3 kg (5.07 lbs)
Battery	6-cell Lithium-Ion
CPU	Intel Core 2 Duo
