6–4 Maintenance and Service Guide
Specifications
Table 6-3
Hard Drives
160-GB* 120-GB*
Dimensions
Height
Width
Weight
9.5 mm
70 mm
102 g
9.5 mm
70 mm
99 g
Interface type ATA - 7 ATA - 5
Transfer rate
Synchronous (maximum)
Security
150 MB/sec
ATA s e c ur i ty
100 MB/sec
ATA security
Seek times (typical read, including setting)
Single track
Average
Maximum
2 ms
12 ms
21 ms
3 ms
13 ms
24 ms
Logical blocks† 312,581,808 234,433,260
Disk rotational speed 5400 rpm
Operating temperature 5°C to 60°C
(41°F to 140°F)
5°C to 55°C
(41°F to 131°F)
✎
Certain restrictions and exclusions apply. For details, consult technical
support by selecting Start > Help and Support > Contact support.
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Accessible
capacity is less.
†Actual drive specifications may differ slightly.
