Product Description
Maintenance and Service Guide 1–17
The external components on the bottom of the computer
are shown below and described in Table 1-7.
Bottom Components
Table 1-7
Bottom Components
Item Component Function
1 Battery bay Holds the battery.
2 Battery release latch Releases the battery from the battery
bay.
3 Optical drive Reads an optical disc.
4 Hard drive bay Holds the hard drive.
