HP Compaq V3000 User Manual

5–52 Maintenance and Service Guide
Removal and Replacement Procedures
5.16 Modem Module
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Mini Card compartment cover (Section 5.8)
❏ Optical drive (Section 5.9)
❏ Keyboard (Section 5.10)
❏ Switch cover (Section 5.11)
❏ Display assembly (Section 5.12)
❏ Top cover (Section 5.13)
Modem Module Spare Part Number Information
For use with computer models using Intel processors
For use with computer models using AMD processors
417083-001
431852-001

HP Compaq V3000 Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Display	14.1-inch WXGA (1280 x 800) TFT LCD
Hard Drive	120 GB SATA (5400 rpm)
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g
Operating System	Windows XP Professional
Weight	2.3 kg (5.07 lbs)
Battery	6-cell Lithium-Ion
CPU	Intel Core 2 Duo
