1–10 Maintenance and Service Guide
Product Description
Table 1-3
Left-Side Components
Item Component Function
1 S-Video-out jack Connects an optional S-Video device such
as a television, VCR, camcorder, overhead
projector, or video capture card.
2 External monitor port Connects an external VGA monitor or
projector.
3 Expansion port 3 Connects the computer to an optional
expansion product.
✎
The computer has only one
expansion port. The term
expansion port 3
describes the
type of expansion port.
4 RJ-45 (network) jack Connects a network cable.
5 USB port Connects an optional USB device.
6 1394 port Connects an optional IEEE 1394 or 1394a
device, such as a camcorder.
7 Memory Reader Supports the following optional digital card
formats: Secure Digital (SD) Memory Card,
MultiMediaCard (MMC), Secure Digital
Input/Output (SD I/O), Memory Stick (MS),
Memory Stick Pro (MSP), xD-Picture Card
(XD), xDPicture Card (XD) Type M.
8 Memory Reader light On: A digital card is being accessed.
9 ExpressCard slot Supports optional ExpressCard/54 cards.
