Specifications
Maintenance and Service Guide 6–3
Table 6-2
14.0-inch, WXGA, SVA Display
Dimensions
Height
Width
Diagonal
27.94 cm
20.83 cm
35.56 cm
11.0 in
8.2 in
14.0 in
Number of colors Up to 16.8 million
Contrast ratio 250:1
Brightness 180 nits typical
Pixel resolution
Pitch
Format
Configuration
0.279 × 0.279 mm
1280 × 768
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 4 W
Viewing angle +/-40° horizontal, +20/-40° vertical
typical

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq V3000 and is the answer not in the manual?

HP Compaq V3000 Specifications

General IconGeneral
GraphicsIntel Graphics Media Accelerator 950
Display14.1-inch WXGA (1280 x 800) TFT LCD
Hard Drive120 GB SATA (5400 rpm)
Optical DriveDVD±RW DL LightScribe
Wireless802.11a/b/g
Operating SystemWindows XP Professional
Weight2.3 kg (5.07 lbs)
Battery6-cell Lithium-Ion
CPUIntel Core 2 Duo
