Removal and Replacement Procedures
Maintenance and Service Guide 5–13
2. Loosen the two Phillips PM2.0×5.0 screws 1 that secure
the memory module compartment cover to the computer.
3. Lift the right edge of the memory module compartment
cover 2, and then swing it to the left.
4. Remove the memory module compartment cover.
✎
The memory module compartment cover is included in the
Plastics Kit, spare part number 417074-001.
Removing the Memory Module Compartment Cover
