Removal and Replacement Procedures

Maintenance and Service Guide 5–31

4. Turn the computer display-side up with the front toward you.

5. Open the display as far as possible.

6. Disconnect the following cables:

1 Display cable

2 Display lid switch module cable

3 Microphone cable

7. Remove the wireless antenna cables 4 from the hole in the

system board.

Disconnecting the Display and Microphone Cables and Removing

the Wireless Antenna Cables
