Removal and Replacement Procedures
Maintenance and Service Guide 5–35
13. Remove the two black Phillips PM2.5×5.0 screws 1 that
secure the inverter to the display enclosure.
14. Remove the inverter 2 from the display enclosure.
15. Disconnect the display cable 3 and the backlight cable
4 from the display inverter.
Removing the Display Inverter
Display Assembly Subcomponents
Spare Part Number Information
Display inverter 417097-001
