HP Compaq V3000 User Manual

Removal and Replacement Procedures
Maintenance and Service Guide 5–41
✎
The microphone and cable are included in the Display Cable
Kit, spare part number 430904-001.
28. If it is necessary to replace the microphones and cables,
release the retention tabs 1 built in to the display enclosure
lining that secure the microphones and cables to the
display enclosure.
29. Remove the microphones from the clips 2 in the
display enclosure.
30. Remove the microphone cables 3 from the display enclosure.
Removing the Microphones
Reverse the above procedure to reassemble and install the
display assembly

HP Compaq V3000 Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Display	14.1-inch WXGA (1280 x 800) TFT LCD
Hard Drive	120 GB SATA (5400 rpm)
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g
Operating System	Windows XP Professional
Weight	2.3 kg (5.07 lbs)
Battery	6-cell Lithium-Ion
CPU	Intel Core 2 Duo
