HP Compaq V3000 User Manual

Removal and Replacement Procedures
Maintenance and Service Guide 5–55
2. Release the ZIF connector to which the audio/infrared board
cable is connected and disconnect the cable 1 from the
system board.
3. Remove the silver Phillips PM2.5×5.0 screw 2 that secures
the audio/infrared board to the computer.
4. Lift the rear edge of the audio/infrared board 3 and swing it
forward until the audio connectors disengage from the
base enclosure.
5. Remove the audio/infrared board 4.
Removing the Audio/Infrared Board
Reverse the above procedure to install the audio/infrared board.

HP Compaq V3000 Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Display	14.1-inch WXGA (1280 x 800) TFT LCD
Hard Drive	120 GB SATA (5400 rpm)
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g
Operating System	Windows XP Professional
Weight	2.3 kg (5.07 lbs)
Battery	6-cell Lithium-Ion
CPU	Intel Core 2 Duo
