Removal and Replacement Procedures
Maintenance and Service Guide 5–77
✎
The following note applies only to computer models using
AMD processors:
The fan/heat sink assembly mounting bracket should be replaced
as shown in the following illustration when installing the fan/heat
sink assembly.
The fan/heat sink assembly mounting bracket is available using
spare part number 417114-001.
Removing the Fan/Heat Sink Assembly Mounting Bracket
Reverse the above procedure to install the fan/heat sink assembly.
