HP Compaq V3000 User Manual

A–2 Maintenance and Service Guide
Screw Listing
Black Phillips PM2.0×5.0 Captive Screw Locations
Table A-2
Black Phillips PM2.0×5.0 Captive Screw
Color Qty. Length Thread
Head
Width
Black 5 5.0 mm 2.0 mm 4.0 mm
Where used:
1 Two screws that secure the hard drive cover to the computer (screws are
captured on the cover by C-clips; documented in Section 5.4)
2 Two screws that secure the memory module compartment cover to the
computer (screws are captured on the cover by C-clips; documented in
Section 5.7)
3 One screw that secures the Mini Card compartment cover to the computer
(screw is captured on the cover by a C-clip; documented in Section 5.8)
mm

HP Compaq V3000 Specifications

General

Graphics	Intel Graphics Media Accelerator 950
Display	14.1-inch WXGA (1280 x 800) TFT LCD
Hard Drive	120 GB SATA (5400 rpm)
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g
Operating System	Windows XP Professional
Weight	2.3 kg (5.07 lbs)
Battery	6-cell Lithium-Ion
CPU	Intel Core 2 Duo
