A–38 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×9.0 Spring-Loaded Shoulder Screw Location
Table A-13
Phillips PM2.0×9.0 Spring-Loaded Shoulder Screw
(Continued)
Color Qty. Length Thread
Head
Width
Silver 2 9.0 mm 2.0 mm 4.0 mm
Where used:
One screw that secures the fan/heat sink assembly to the system board on
computer models using AMD processors (documented in Section 5.23)
mm
