Illustrated Parts Catalog
Maintenance and Service Guide 3–19
Table 3-2
Display Assembly Components
Spare Part Number Information
Item Description
Spare Part
Number
1a
1b
Display Plastics Kit
For use with full-featured computer models
For use with defeatured computer models
Includes:
■ Display bezel
■ Display enclosure
430472-001
417101-001
2a
2b
Display inverter, includes
Display inverter bracket
417097-001
3 Wireless antenna transceivers and cables 417107-001
4 Display panels
14.1-inch, WXGA, SVA display panel with BrightView
For use with V3200 models, BV panel
For use with V3200 models, CAY panel
14.1-inch WXGA AG with microphone, for full-featured
models
14.1-inch WXGA AG for defeatured models
430459-001
435842-001
435843-001
435856-001
435855-001
5 Display Hinge Kit (includes left and right
display hinges)
417103-001
6 Display Cable Kit (includes microphones and cables) 430904-001
7 Display lid switch module (includes display lid
switch module cable)
431881-001
Display Label Kit (not illustrated) 417111-001
Display Screw Kit (includes screws and rubber
screw covers, not illustrated)
417105-001
Web camera (includes Web camera bracket; not
illustrated)
417113-001
