Display panel
NOTE: These procedures are for replacing the display panel for HP 215 G1 PC non-touchscreen
models only. For procedures to replace the display assembly for the HP Pavilion TouchSmart 11
Notebook PC, HP Pavilion 11 Notebook PC, or the HP 215 G1 PC TouchSmart models, see
Display
assembly on page 46. For procedures to replace the display assembly subcomponents for the HP
215 G1 PC non-touchscreen models, see
Display assembly on page 46 and then Display assembly
subcomponents on page 49.
Description Spare part number
Display bezel 744179-001
Display panel, 11.6 inch (29.46 cm) flat display panel, HD WLED AG (1366 x 768) (3.6 mm)
Standard Viewing Angle, non-touchscreen
744182-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement
Before removing the display panel, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 33).
Remove the display panel:
1. Remove the plastic screw covers (1) and the two Phillips screws (2) that secure the display
bezel to the display assembly.
42 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
