Display assembly
NOTE: HP Pavilion TouchSmart 11 Notebooks, HP Pavilion 11 Notebooks, and HP 215 G1
Notebook PC TouchSmart models are spared at the display assembly only. The display assembly for
the HP 215 G1 Notebook PC non-touchscreen models is spared at the subcomponent-level only. For
procedures to replace the display assembly subcomponents for the HP 215 G1 Notebook PC non-
touchscreen models, see
Display assembly subcomponents on page 49.
Description Spare part number
11.6 inch (29.46 cm), AG, SVA, LED TouchSmart display assembly (includes webcamera/
microphone module and wireless antenna cables)
753948-001
Before removing the display assembly, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 33).
5. Remove the service door (see
Service door on page 34).
Remove the display assembly:
1. Remove the rear rubber feet (1).
The rear rubber feet are included in the Rubber Feet Kit, spare part number 730888-001.
2. Remove the two Phillips PM2.2×5.5 screws (2) that secure the rear corner covers to
the computer.
46 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
