Display assembly subcomponents
NOTE: These procedures are for replacing the display assembly internal components for the HP
215 G1 Notebook PC non-touchscreen models only.
Component Spare part number
Antenna Kit (includes left and right wireless antenna cables and transceivers) 744177-001
Display back cover 744178-001
Display Hinge Kit (includes left and right hinges) 744181-001
Display panel cable (includes webcamera/microphone module cable) 744180-001
Screw pad (includes display screws) 744184-001
Webcamera/microphone module 754263-001
Before removing the display assembly subcomponents, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 33).
5. Remove the service door (see
Service door on page 34).
6. Remove the display panel (see
Display panel on page 42).
7. Remove the display assembly (see
Display assembly on page 46).
Remove the display assembly subcomponents:
1. If it is necessary to replace the webcamera/microphone module:
a. Detach the webcamera/microphone module (1) from the display back cover.
Component replacement procedures 49
