b. Disconnect the webcamera/microphone module cable (2) from the webcamera/microphone
module. (The webcamera/microphone module cable is part of the display panel cable.)
2. If it is necessary to replace the hinges:
a. Remove the six bottom screws (1) from the display hinges.
b. Remove the hinges (2) from the display enclosure.
3. If it is necessary to replace the display panel cable:
a. Release the microphone (1).
50 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
