b. Use a tool to release the bottom edge of the display bezel (1) from the display assembly.
IMPORTANT: Be careful not to bend or break the narrow sections of the bezel when removing.
c. Release the left and right edges of the display bezel (2) from the display assembly.
d. Release the top of the display bezel (3) from the display assembly.
e. Remove the display bezel (4).
The display bezel is available as spare part number L64907-001.
7. If it is necessary to remove the webcam module:
▲ Starting from the side, use a tool to lift and release (1) the webcam module from the metal tape
behind it (2). Remove the module from the display back cover (3), and then disconnect the cable
(4).
The webcam is available as spare part number L64914-001.
52 Chapter 5 Removal and replacement procedures for authorized service provider parts
