Mounting Hole Dimensions
Table 1. Mounting Hole Dimensions
Switch Model Hole-to-Hole Dimension
1410-8 3.54 inch (90.0 mm)
1410-16 5.91 inch (150.0 mm)
1410-24 5.91 inch (150.0 mm)
1410-24-2G 5.91 inch (150.0 mm)
Russia/Belarus/Kazakhstan/CEE Safety:
(Under-table mounting)
After installation, prevent switch movement
by placing a third screw along this side.
Hole-to-Hole Dimension
(See Table 1)
