HP 16600A Series User Manual

15
16allp15
CD-ROM DriveCD-ROM Drive
CD-ROM DriveCD-ROM
Drive
Termination Plug
(50 pin)
CD-ROM Drive
Cable
HP 16700A or
HP 16702A
HP 16600A
Series
1
To16701 Expansion FrameTo 16701 Expansion Frame
Target
Control
Target
Control
Keyboard Mouse
Keyboard Mouse
RS 232 Monitor Parallel Printer
LAN
10Base-T
SCSI-2 Single Ended
LAN
10Base2
Target
Control
Out - Port - In
HP 16600A Series/ HP 16700A/ HP 16702A
CD-ROM Drive
(50 pin)
(50 pin)
A CD-ROM drive address
setting of 6 or 7 could damage
your hard drive.
CAUTION
Set the CD-ROM drive address to 2.
