HP 16600A Series User Manual

9
16allp09
Enter
Selection made and
"Y" to confirm.
Monitor power
(Cycling choices)
System power
1
If you ordered the optional monitor with your logic analyzer, the monitor resolution setting is
pre-configured for 1280 x 1024 at the factory.
If you already have a monitor and ordered your logic analysis system without the optional
monitor, you will need to configure your monitor. The display will change on the screen every
few seconds as the system cycles through the monitor resolution choices. Make the
appropriate selection when it appears.
(Your monitor)
16700A
LogicAnalysis System
Power
Busy
HP 16600A Series
HP 16700A
HP 16600A Series and HP 16700A
Monitor ConfigurationMonitor Configuration
Monitor ConfigurationMonitor
Configuration
3
2
Monitor choice.
Clear
Images
