HP 16600A Series User Manual

19
16allp31
External Disk Drive & CD-ROMExternal Disk Drive & CD-ROM
External Disk Drive & CD-ROMExternal
Disk Drive & CD-ROM
Termination Plug
CD-ROM Drive
Cable
External Disk Drive
Cable
(50 pin to 68 pin)
HP 16700A or HP 16702A
HP 16600A Series
To16701 Expansion FrameTo 16701 Expansion Frame
Target
Control
Target
Control
Keyboard Mouse
A CD-ROM drive and an external disk drive(s)
may be connected to the system at the same
time.
Keyboard Mouse
RS 232 Monitor Parallel Printer
LAN
10Base-T
SCSI-2 Single Ended
LAN
10Base2
Target
Control
Out - Port - In
HP 16600A Series/ HP 16700A/ HP 16702A
CD-ROM Drive
1
(68 pin)
(50 pin)
(50 pin)
(50 pin)
External Disk Drive
(68 pin)
(68 pin)
(50 pin)
