HP 16600A Series User Manual

Be sure the frame is unplugged before
removing or installing modules.
CAUTION
CAUTION
Disconnect the
power cable.
Power
Busy
Power down
the system.
40
modgen
Insert
or filler panels.
modules
(Other or
filler panels.)
modules
Remove
or filler panels.
modules
(Other or
filler panels.)
modules
4
2
5
for HP 16600A Series/ HP 16700A/ HP 16702A
Measurement ModulesMeasurement Modules
Measurement ModulesMeasurement
Modules
General Installation
Use a grounded wrist strap and mat when handling the . Gently apply pressure to
the center of the module or filler panel while tightening the thumb screws. Use filler panels in
empty slots for proper cooling.
Some require calibration if they are moved to a different slot. For calibration
information, refer to the online help for the individual .
modules
module
A single-module configuration can be installed in any available slot.
modules
modules
Carefully slide the into the frame and hand tighten the thumb screws. If you are
inserting more than one , the tightening order is bottom to top .module module module
3
1
