HP 16600A Series User Manual

24
16allp20
HP 16700A/ HP 16702A
HP 16701A Expander FrameHP 16701A Expander Frame
HP 16701A Expander FrameHP
16701A Expander Frame
Connect the desired length
interconnect cable and tighten the
connector screws with the screw
driver provided.
Install your measurement modules
in the HP 16701A expander frame.
Connect the power cable to the
HP 16701A.
Power up the HP 16700A
or HP 16702A system.
To 16701 ExpansionFrameTo 16701 Expansion Frame
Target
Control
Target
Control
Keyboard Mouse
HP 16701A Interconnect Cable
Choose from the 30cm (12 inch) length,
or the 90 cm (36 inch) length.
HP 16700A or HP 16702A
HP 16701A
2
1
3
4
