16533p08

for HP 16700A and HP 16702A

Multi-Card Module

HP 16533/34A CalibrationHP 16533/34A Calibration

HP 16533/34A CalibrationHP

16533/34A Calibration

Each of the individual boards of a multi-card module must first be calibrated as a

single. (See previous pages: .)

The following example is of a two-card module arrangement. Up to four cards may be

configured as a module in an HP 16700A or an HP 16702A mainframe.

HP 16533/34A Single-Card Module

Connect the module cables.

Exit the current session and restart.

Master
