HP 16600A Series - Page 70

69
16557p04
HP 16557DHP 16557D
HP 16557DHP
16557D
2-Card Module
2x25 Cables
(Need 2)
2x10 Cables
Expander
Master
Master
J3J9J10
Expander
J6
J6
J8
J8
J5
J5
J7
J7
J4
J4
J3J9J10
MASTER
EXPANDER
Find the required two connector
and connect the cables as shown.
2x25 cables
Connect the on the
Expander to the Master.
2x10 cables
for HP 16700A and HP 16702A
