A–36 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×13.0 Spring-Loaded Shoulder Screw Locations
Table A-12
Phillips PM2.0×13.0 Spring-Loaded Shoulder Screw
(Continued)
Color Qty. Length Thread
Head
Width
Silver 8 13.0 mm 2.0 mm 6.0 mm
Where used:
4 screws that secure the fan/heat sink assembly to the system board on
computer models using AMD processors (documented in Section 5.25)
mm
