Screw Listing
Maintenance and Service Guide A–37
Phillips PM2.0×9.0 Spring-Loaded Shoulder Screw Location
Table A-13
Phillips PM2.0×9.0 Spring-Loaded Shoulder Screw
Color Qty. Length Thread
Head
Width
Silver 2 9.0 mm 2.0 mm 6.0 mm
Where used:
One screw that secures the fan/heat sink assembly to the system board on
computer models using Intel processors (documented in Section 5.25)
mm
