Table 3-1 Computer major components and their descriptions
Item Component Spare part
number
(1) Display
NOTE: Displays are not spared as whole units. Display subcomponent spare parts are available. For
spare part information, see Display assembly subcomponents on page 19.
Not spared
(2) Top cover/keyboard
NOTE: For a detailed list of country codes, see Top cover with keyboard on page 66.
Keyboard, jet black, for use in the United States L50000-xx1
Keyboard, silver, for use in Saudi Arabia L50001-xx1
(3) TouchPad module L20449-001
(4) TouchPad button board not spared
(5) Speakers (includes cable) L20453-001
(6) Power connector cable (DC-in) L20475-001
(7) System board
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
AMD Ryzen 3-2200U processor L50003-xx1
AMD A9-9425 processor L50004-xx1
AMD A6-9225 processor L50005-xx1
AMD A4-9125 processor L54792-xx1
AMD E2-9000e processor L50006-xx1
(8) Solid-state drive
NOTE: For spare part information, see Mass storage devices on page 21.
(9) Memory modules (DDR4-2666)
8 GB 937236-855
4 GB L10598-855
(10) WLAN module
Realtek RTL8821CE 802.11ac 1 × 1 WiFi + Bluetooth 4.2 Combo Adapter (MU-MIMO supported) L17365-005
(11) Hard drive connector board L20454-001
(12) Solid-state drive connector board L20457-001
(13) Fan L20474-001
Heat sink
(14) For use in models with AMD Ryzen processors L20483-001
For use in models with AMD A6/A9 processors L20491-001
16 Chapter 3 Illustrated parts catalog
