Display assembly subcomponents
Table 3-3 Display components and their descriptions
Item Component Spare part number
(1) Hinge cover
Asteroid silver L49990-001
Dark ash silver L49991-001
(2) Display bezel L20421-001
(3) Display panel
HD L50021-001
FHD L50022-001
Miscellaneous Display Kit (includes gaskets [4] and rubber corner positioning tools [4]; not
illustrated))
L23065-001
Display panel stretchable adhesive tape (not illustrated) L29080-001
(4) Hinge Kit (includes left and right hinges) L20420-001
(5) Display cable
Non-touch, HD L20443-001
Display assembly subcomponents 19
