Optical drive
Table 5-1 Spare part description and number
Description Spare part number
DVD+/-RW Double-Layer Writer L50025-001
Optical drive bracket L20459-001
Optical drive bezel - asteroid silver L49988-001
Optical drive bezel - dark ash silver L49989-001
Before removing the optical drive, follow these steps:
▲
Prepare the computer for disassembly (Preparation for disassembly on page 27).
Remove the optical drive:
1. Remove the Phillips M2.5 × 9.0 screw (1) that secures the drive to the computer.
2. Slide the optical drive out of the computer (2).
28 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
