Speakers
Table 6-15 Spare part description and number
Description Spare part number
Speaker Kit L20453-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 27).
2. Remove the optical drive (see Optical drive on page 28).
3. Remove the bottom cover (see Bottom cover on page 31).
4. Remove the battery (see Battery on page 33).
5. Remove the display (see Display assembly on page 53).
Remove the speakers:
1. Remove the speaker cable from the clips built into the computer (1).
2. Remove the speakers from the computer (2).
Reverse this procedure to install the speakers.
64 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
