Solid-state drive
Table 6-5 Spare part description and number
Description Spare part number
256 GB, SATA-3, TLC L50020-001
128 GB, SATA-3, TLC L50019-001
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 27).
2. Remove the optical drive (see Optical drive on page 28).
3. Remove the bottom cover (see Bottom cover on page 31).
4. Remove the battery (see Battery on page 33).
Remove the solid-state drive:
▲
Remove the Phillips M2.0 × 3.0 screw (1), and then pull the solid-state drive module from the socket (2).
Reverse this procedure to install the solid-state drive.
Component replacement procedures 39
